COMPACTPCI SC2650-4-S Control Board

COMPACTPCI SC2650-4-S Control Board

 Introduction

COMPACTPCI SC2650-4-S Control Board

Standard 3U CPCI industrial control board, used for overall logic control of semiconductor and automation equipment

1. Following the CompactPCI bus standard, the chassis is directly inserted for installation

2. 4 independent signal channels, collecting sensing and execution signals

3. Channel electrical isolation, anti workshop electromagnetic interference

4. Multiple overcurrent and electrostatic hardware protection

5. Onboard status indicator light, quick fault location

6. Industrial wide temperature design, 24-hour stable operation

7. Gold finger gold-plated, shock resistant and not easy to contact poorly

8. Support hot swapping, convenient shutdown maintenance

9. Compatible with mainstream industrial control systems, low communication latency

10. PCB strong and weak electrical zoning wiring, signal crosstalk free

11. Built in hardware watchdog, automatically reset in case of abnormalities

12. High temperature resistant components, suitable for dust-free workshop conditions

13. Reserved expansion slot, capable of installing acquisition daughter cards

14. Automatic hardware self-test upon startup, verifying all circuits

15. Compliant with industrial EMC safety standards, durable and reliable

Overall, the SC2650-4-S control board bus is universal, well protected, and easy to maintain, making it a core computing and control spare part for industrial equipment

Product imag
