 Introduction

B&R X20IF1041-1 Interface Module

B&R X20IF1041-1 is an X20 series CANopen master communication interface module used for external third-party devices to achieve bus data exchange.

1. The B&R X20IF1041-1 comes with a CANopen master communication channel, compatible with various CANopen slave devices

2. Module electrical isolation design, isolating bus and PLC circuit, with strong anti-interference ability

3. Built in switchable terminal resistor, no need to install additional matching resistors

4. Maximum communication speed of 1Mbps, stable long-distance data transmission

5. The maximum transmission distance of the bus can reach 1000 meters, suitable for large-scale production line layouts

6. Equipped with netX100 communication chip, 8MB cache, smooth data processing

7. Multiple sets of LED status lights for intuitive viewing of module, bus, and terminal resistance status

8. 5-pin standard terminal block, neat wiring, easy disassembly and wiring

9. Can directly insert X20 controller and X20BC1083 bus extender

10. Rail buckle installation, both horizontal and vertical cabinets can be assembled, occupying small space

11. Wide temperature stable operation, suitable for high and low temperature working conditions in the workshop environment

12. Bidirectional high-speed data transmission and reception, docking with external devices such as servo and sensors

13. Equipped with hardware diagnostic function, software can read bus fault information

14. Compliant with industrial IP20 protection, dustproof and moisture-proof, suitable for industrial control scenarios

15. Standardized X20 bus backplane, flexible expansion through multi module splicing

In summary, the B&R X20IF1041-1 interface module has stable communication, easy installation, and intuitive diagnosis, making it a standard communication spare part for the B&R X20 system to interface with third-party bus devices.

Product imag
