Advantech ASMB-925 motherboard

Advantech ASMB-925 motherboard

 Introduction

Advantech ASMB-925 motherboard product features

EATX standard version, equipped with dual LGA3647 slots, supports Xeon expandable processors

Equipped with 12 sets of DDR4 memory slots, it can expand up to 1.5TB of high-speed cache memory

Equipped with C621 industrial grade chipset, the computing power is stable and suitable for industrial big data computing

5-way PCIe 3.0 x16, 1-way PCIe 3.0 x8+1-way traditional PCI, with strong compatibility for expansion

Onboard dual 10 Gigabit Intel X557 Ethernet ports, supporting link redundancy and high-speed data transmission

8 sets of SATA3.0 storage interfaces, supporting multiple hard disk arrays, with sufficient local storage capacity

6-way USB 3.0 interface, convenient for external acquisition card and debugging device expansion

Built in AST2500 display chip, built-in VGA output, independent monitoring of the screen

Integrated IPMI2.0 remote management, remote power on/off, monitoring hardware operation status

Equipped with TPM2.0 secure encryption chip, industrial data theft and tampering prevention

Programmable hardware watchdog, automatic reset upon system crash, ensuring uninterrupted operation of the production line

7-way fan speed control interface, intelligent temperature control, controllable temperature rise under full load for a long time

0-40 ℃ industrial wide temperature operation, suitable for computer rooms, semiconductor equipment industrial control scenarios

Support software RAID0/1/5/10, data backup, reduce storage failure risk

Complete industrial EMC electromagnetic protection to resist workshop RF and motor interference signals

The Advantech ASMB-925 motherboard is a dual channel high-performance industrial server control board with rich expansion capabilities and convenient remote operation and maintenance, suitable for testing, wafer, and automation equipment hosts.
