ADLINK CPCI-6503VED Single Board Computer

ADLINK CPCI-6503VED Single Board Computer

 Introduction

ADLINK CPCI-6503VED Single Board Computer Product Features

Standard 6U CompactPCI architecture, compatible with industrial standard chassis backboards

Equipped with a low-power embedded processor, it generates low heat during long-term operation

Onboard large capacity DDR3 memory, sufficient and stable data operation cache

Dual Gigabit Ethernet ports meet the high-speed data exchange needs of multiple devices

Integrated VGA+LVDS dual display output, capable of dual screen synchronous operation

Multi channel RS232/485 serial port, compatible with various industrial peripheral communication

Comes with SATA storage interface, can be equipped with SSD for local data storage

Front USB 2.0 expansion port, easy to debug and plug in peripherals

Support supporting rear RTM adapter board to simplify internal wiring of the cabinet

Wide temperature industrial grade design, continuous operation of high and low temperature workshop conditions

The whole machine is reinforced with PCB and locking handle, with strong seismic and impact resistance

Built in SEMA device management function, remote monitoring of the overall machine status

Supports multiple industrial operating systems including Windows, Linux, and VxWorks

Optional moisture-proof three proof coating, suitable for dusty and humid production environments

Modular plug-in structure, quick replacement of faults, and shortened maintenance time

ADLINK CPCI-6503VED single board computer is a dedicated main control board for industrial control and testing equipment, with balanced computing power, strong scalability, and excellent environmental adaptability.

Product imag
