TEL 5868-000002-V1 thyristor control unit

TEL 5868-000002-V1 thyristor control unit

 Introduction

TEL 5868-000002-V1 thyristor control unit product features

TEL 5868-000002-V1 is compatible with Tokyo Electronic Semiconductor Equipment and is responsible for precise adjustment of heating load power.

High precision phase-shift trigger control, fine tune thyristor conduction angle, and smoothly adjust output power

Contactless thyristor switch structure, no mechanical wear, fast start stop response speed

Built in real-time current and voltage acquisition, closed-loop dynamic correction output, strong temperature control consistency

Optoelectronic isolation control circuit, isolated from radio frequency interference, suitable for complex electromagnetic environments such as etching and deposition

Multiple hardware protection, automatic output cut-off for overcurrent, phase loss, overheating, and short circuit

Original factory exclusive communication bus, which can synchronize power and fault data with the main control of the whole machine

Power on automatic self check calibration trigger circuit to avoid power output offset

Compact integrated module, saving installation space inside the equipment control cabinet

Efficient heat dissipation structure, less prone to overheating and power reduction during long-term high-power operation

Slow start and slow shutdown function, reducing power grid impact and protecting heating components

Multi layer isolated PCB wiring, strong and weak electrical zoning, reducing signal crosstalk distortion

Non volatile storage retains power parameters, no need to re debug after power failure and restart

Standardized plug and unplug wiring terminals, separate disassembly and maintenance without the need for complete machine shutdown

Industrial grade reinforced power devices, capable of withstanding long-term vibration and stable operation of the production line

Native matching TEL wafer process equipment, can directly replace old units of the same specifications

TEL 5868-000002-V1 is the core power control component of semiconductor heating systems, ensuring stable and controllable process temperature.
