WAVETREAM MBP-000300-D000 processor module

WAVETREAM MBP-000300-D000 processor module

Product Details Introduction

WAVETREAM MBP-000300-D000 processor module

Introduction: This WAVETREAM module is a main control unit equipped with a 300W BUC RF up converter, which controls the RF power output and overall operating status of the machine.

Built in dedicated processing chip, real-time calculation of RF output parameters

Accurately regulate output power to ensure stable satellite communication signals

Integrated multi-channel monitoring circuit, collecting voltage, current, and temperature data

Comes with RS232/485 communication and supports remote control by the upper computer

Real time standing wave detection, abnormal standing wave automatic power reduction protection amplifier

Multi level power adjustable, suitable for signal transmission needs at different distances

Built in fault self check, quick identification of overheating and overcurrent faults

Aluminum alloy integrated heat dissipation shell, stable temperature control during long-term operation

Multi specification industrial aviation plug interface, matched with original factory cables for direct docking

Wide DC voltage input, suitable for various power supply environments in field computer rooms

Digital pre distortion algorithm to reduce RF signal distortion loss

Sealed dust-proof body, suitable for harsh outdoor and in car working conditions

Support parameter storage during operation, data will not be lost after power failure

Standardized installation holes, quick fixing and assembly of equipment cabinets

Suitable for Ku/C band satellite launch RF complete set of units

Conclusion: WAVETREAM MBP-000300-D000 has stable operation and complete protection, and is a core control spare part for high-power satellite RF equipment.

Product imag
