TEL 5880-000011-V1 PCB Rack Assembly

TEL 5880-000011-V1 PCB Rack Assembly

Product Details Introduction

TEL 5880-000011-V1 PCB Rack Assembly

Introduction: This TEL rack assembly is used to place various control PCB boards and achieve centralized assembly of equipment control modules.

Original factory matching size, compatible with corresponding semiconductor process equipment board

Multi slot layered structure, capable of simultaneously installing multiple functional circuit boards

Built in integrated backplane for signal interconnection between boards

Side ventilation channel ensures continuous operation and heat dissipation of the board

Metal reinforced frame, resistant to vibration and not easily deformed or loose

Partition wiring trough, separate strong and weak electricity to reduce signal interference

Equipped with fixed buckles, the installation and disassembly of the board is simple and fast

Integrate public power supply lines to provide unified power supply to each board

Corrosion resistant coating on the shell, suitable for clean workshop conditions

Reserve grounding points to eliminate static interference on line signals

Front and rear detachable cover plates, convenient for daily maintenance and replacement of boards

Internal cable slot, tidy up the circuit and easy to troubleshoot faults

Wide temperature resistant material, capable of 24-hour uninterrupted operation

Standard installation hole position, can be fixed inside the equipment cabinet

Carrying IO, communication, and main control board, coordinating the control signals of the entire machine

Conclusion: TEL 5880-000011-V1 has a stable and highly integrated structure, and is a dedicated load-bearing component for semiconductor equipment PCB boards.

Product imag
