AMAT 0190-51510 Robot Controller

AMAT 0190-51510 Robot Controller

Product Details Introduction

AMAT 0190-51510 is a dedicated main control unit for Kawasaki robotic arms, which is a specialized semiconductor wafer transfer chamber equipment. It is the core central component of wafer handling robotic arms.

1. Specially designed for 300mm wafer processing, controlling the entire process of mechanical arm picking and placing wafers in the vacuum chamber

2. Equipped with exclusive motion algorithm, micrometer level repetitive positioning, avoiding wafer collision and edge damage

3. The board is fully coated with three anti coatings, suitable for temperature controlled and low dust sealed working conditions in dust-free workshops

4. Integrate multiple safety interlocks for vacuum pressure and chamber doors, and immediately lock the action of the robotic arm in case of abnormalities

5. Equipped with a power-off trajectory storage chip, accidental shutdown and restart do not require recalibration of the origin point

6. Built in dedicated communication protocol, directly connected to AMAT host process system, synchronized interactive cavity process parameters

7. Onboard EMI filtering circuit to isolate RF power interference in the cavity and eliminate the problem of running and losing steps

8. Gold plated industrial terminal interface ensures long-term stability of electrical connections under frequent reciprocating working conditions

9. Partition modular hardware layout, fault partition maintenance, no need to shut down the entire controller for replacement

10. Dynamic load adaptive tuning, autonomously adjusting output torque based on the weight of a single wafer/whole box of wafers

11. Multiple sets of reserved digital IO points, expandable for docking with vacuum valves, gas pipeline auxiliary components

12. Narrow rack installation structure, fitting AMAT equipment's native cabinet openings, easy to replace and modify

13. 24-hour full load tolerance, adapted to the uninterrupted production rhythm of wafer fabs

14. Embedded fault code log storage, retain operation records, and quickly locate hidden operational hazards

15. Original firmware encryption adaptation, only compatible with robotic arms of the same series, highly targeted compatibility

This controller is an original spare part for AMAT thin film deposition and etching equipment manipulator, and a high-frequency spare part for wafer manufacturing production line maintenance and replacement.

Product imag
