Bobst 0704151202 NFC25-24T05-15 Controller Module

Bobst 0704151202 NFC25-24T05-15 Controller Module

Product Details Introduction

Bobst 0704151202 NFC25-24T05-15 Controller Module

1. Original compatible with Bobst glue box/flat die-cutting models, integrated with a main control driver and isolation power supply structure, model NFC25-24T05-15 is the onboard power supply specification, and 0704151202 is the original material code.

2. Built in 24V to 5V isolated and stabilized power supply, providing stable power supply for onboard MCU and communication chips, and adapting to voltage fluctuations in the workshop power grid.

3. Integrate multiple DI/DO signal circuits, collect equipment limit and feed detection signals, and output control solenoid valves and small actuators.

4. Optoelectronic isolation strong and weak electrical partition wiring, blocking servo motor frequency conversion interference, and preventing high voltage from entering and burning the main control chip.

5. Gold plated European style plug-in terminals are resistant to oil, toner, dust, and humid environments, and are not prone to oxidation or virtual connection when plugged in for a long time.

6. Equipped with four layers of protection including overvoltage, overcurrent, short circuit, and overheating, and self-locking power-off protection components for load short circuit.

7. Multiple status indicator lights are installed on the board, providing visual illumination for power, communication, and point faults, reducing equipment maintenance and troubleshooting time.

8. Factory fixed exclusive control program, in-situ card slot direct insertion replacement, no need to rewrite parameters, direct production upon power on.

9. The PCB adopts corrosion-resistant solder mask board, which is dust-proof and oil proof, and is suitable for harsh production environments in packaging and printing workshops.

10. Equipped with EMI filtering circuit, it filters out line clutter interference and avoids equipment misoperation caused by signal false triggering.

11. Standard DIN card mounting size, installation of guide rail buckle for electrical control cabinet, disassembly and replacement without changing external wiring.

12. Integrate bus communication interface, connect with 701 series communication board, and achieve data exchange between the main control of the whole machine and the substation.

13. Wide temperature industrial component selection, continuous stable operation from -10 ℃ to+60 ℃, and non-stop operation in high and low temperature workshops.

14. Multiple Bobst old models in the same series are compatible with laminating and die-cutting equipment, and have strong interchangeability of spare parts.

15. The factory's complete machine undergoes a full load power on aging test, with a low failure rate and excellent durability during long-term continuous operation.

The Bobst 0704151202 NFC25-24T05-15 controller module is a core electronic control component that integrates signal acquisition and power supply for Bobst equipment

Product imag

ontroller Module
