Bobst S2100 704-1092-03 Interface Circuit Board

Bobst S2100 704-1092-03 Interface Circuit Board

Product Details Introduction

Bobst iPadOS 0 704-1092-03 Interface Circuit Board

1. Original compatibility with Bobst iPadOS 0 printing alignment equipment, exclusive communication interface design

2. Equipped with high-quality original components, the circuit layout is well-organized, and the ability to resist electromagnetic interference is strong

3. Integrate button panel signal transfer circuit to achieve data exchange between control and main control

4. Suitable for wide temperature conditions, stable and continuous operation in environments ranging from -20 ℃ to 70 ℃

5. Flexible cable docking structure, easy to plug and unplug, stable and not easy to loosen circuit connection

6. High precision signal sampling, equipment with small transmission errors for alignment data, ensuring printing accuracy

7. Standardized board size, can be directly replaced in situ, saving time and effort in disassembly and maintenance

8. Equipped with a short-circuit protection circuit, it effectively protects the entire control system during voltage fluctuations

9. Compatible with the entire range of control programs for S920, it can be debugged on the machine without rewriting parameters

10. Multi layer solder mask PCB board, moisture-proof and oil resistant, suitable for complex working conditions in printing workshops

11. Multiple IO signal channels, with dual functions of key input and indicator light drive

12. After passing the overall online aging test at the factory, the failure rate is low and the service life is long

13. Simplify circuit layout, reduce redundant circuits, and lower the difficulty of troubleshooting

The Bobst S920 704-1092-03 interface circuit board is compatible with the S920 model and is a core component for device human-computer interaction and signal transmission
