BOBST 704-1101-07 Circuit Board

BOBST 704-1101-07 Circuit Board

Product Details Introduction

BOBST 704-1101-07 Circuit Board

BOBST 704-1101-07 is a communication driver board for the 707 series glue box/die-cutting machine, responsible for data exchange between the main control and sub station modules.

1. Multiple sets of bus terminals, connected to IO detection board signals at each workstation

2. 704-1101-07 is equipped with optoelectronic isolation to block workshop clutter interference

3. Three proof solder mask on the board, resistant to ink, dust, and humid working conditions

4. Gold plated fingers, difficult to contact due to device vibration, virtual connection

5. Built in overcurrent protection, backend line fault self-locking protection

6. Layered wiring layout to reduce electromagnetic crosstalk in the circuit

7. Industrial grade surface mount components with stable operation over a wide temperature range

8. Partition layout of status indicator lights, quick troubleshooting of communication faults

9. Standard card slot size, no need to change wires for in-situ insertion and replacement

10. Channel independent circuit, single channel abnormal incomplete board failure

11. Onboard storage chip, saving the communication configuration parameters of the entire machine

12. Thickened PCB substrate, suitable for frequent start stop vibration of equipment

13. Low power line, long-term continuous production with low temperature rise

14. Original factory specific communication protocol, compatible with 704 and 701 series cards

15. BOBST 704-1101-07 is compatible with all packaging equipment in the Bobst 707 series
