BOBST 0701252401 Printed Circuit Board

BOBST 0701252401 Printed Circuit Board

Product Details Introduction

BOBST 0701252401 Printed Circuit Board

BOBST 0701252401 is a dedicated signal interface board for Bosch die-cutting and box pasting machines, responsible for on-site sensor signal acquisition and main control data transfer.

1. Multiple sets of wiring terminals, convenient for connecting photoelectric switches and solenoid valve accessories

2. 0701252401 is equipped with an optoelectronic isolation circuit to isolate strong and weak electrical interference and interference

3. Three proof coating on the board surface, resistant to workshop ink, dust, and moisture condensation

4. Gold plated slot contacts, equipment vibration environment is not easy to oxidize virtual connection

5. Built in overcurrent and short circuit protection, external circuit fault protection for onboard components

6. Layered wiring structure to reduce electromagnetic coupling interference in power lines

7. Original industrial components, stable continuous operation under wide temperature conditions

8. Partition fault indicator light, quickly locate abnormal points

9. Standard card size, in situ plug and replace without changing the cable

10. Each channel has independent circuits, and a single point of failure does not cause the entire board to shut down

11. Onboard storage components retain device operating parameter data

12. Thickened seismic resistant PCB substrate, suitable for frequent start stop vibration of equipment

13. Low power circuit design, long-term mass production with controllable temperature rise

14. Original factory bus protocol, matched with communication docking of the same series of main control boards

15. BOBST 0701252401 is compatible with multiple Bobst 700 series packaging equipment

Applicable equipment: Bosch automatic die-cutting machine, high-speed box pasting machine with electronic control matching.
