BOBST 704-1116-03 power board module

BOBST 704-1116-03 power board module

Product Details Introduction

BOBST 704-1166-03 power board module

BOBST 704-1166-03 is a dedicated multi output switch power board for Bosch die-cutting/box pasting machines, which is the core component for centralized power supply of the whole machine control card, sensors, and relay modules.

1. BOBST 704-1166-03 supports AC mains input, multi-channel DC stabilized output, and adapts to the voltage requirements of multiple specifications of boards, solenoid valves, and optoelectronic components.

2. Built in EMI filtering circuit, filters out workshop power grid clutter, and suppresses voltage disturbances caused by ink dust environment.

3. Integrated overvoltage, overcurrent, and short circuit triple hardware protection, automatically cutting off output in case of abnormal load to prevent the back-end board from burning out.

4. The PCB board is coated with three proof paint, which is moisture-proof, resistant to oil and dust, and suitable for harsh working conditions in packaging workshops.

5. Original gold-plated wiring terminals, resistant to oxidation and virtual connection in long-term vibration environments, with strong wiring stability.

6. Partition and isolate strong and weak electrical wiring, separate high and low voltage circuits, and avoid electrical crosstalk faults.

7. Equipped with temperature control components, automatic power reduction protection against overheating, and controllable temperature rise during long-term full load operation.

8. The panel is equipped with multiple power indicator lights, providing intuitive visualization of single output faults, making maintenance time-saving and efficient.

9. Standard original board size, control cabinet card slot in situ direct insertion replacement, no need to modify wiring circuit.

10. Industrial grade original capacitors and power devices, capable of stable operation over a wide temperature range of -20 ℃ to+70 ℃.

11. Multiple independent voltage regulation circuits, single load faults do not affect the normal power supply of other branches.

12. Equipped with a voltage adjustment potentiometer, it can calibrate the output voltage value as needed on site.

13. Optimize the topology of the switching power supply, with high energy conversion efficiency and low standby power consumption.

14. The 704 model of the same series has a universal electronic control system, good universality of spare parts, and easy stocking and replacement of equipment.

15. BOBST 704-1166-03 original circuit scheme, matched with Bosch's original complete machine power distribution logic.

Applicable models: Bosch automatic box gluing machine, flatbed die-cutting machine, and all series of electrical control cabinet power supply units.
