G122-829-001 servo amplifier

Product Details Introduction

G122-829-001 is a Muge universal PI servo drive module, suitable for closed-loop control of servo valves.

1. Built in dip switch, can freely switch between proportional and integral control modes.

2. G122-829-001 is equipped with three signal input ports, compatible with differential and single ended analog signals.

3. The panel is equipped with an adjustable potentiometer, allowing for easy fine-tuning of on-site gain parameters.

4. Equipped with indicator lights and testing points, troubleshooting is intuitive and efficient.

5. Standard DIN rail buckle installation, cabinet disassembly and assembly saves time and space.

6. DC 24V power supply, low power consumption, and controllable temperature rise for continuous operation.

7. The output current of multiple gears can be adjusted to meet the driving needs of multiple servo valves.

8. Design anti-interference circuits to avoid electromagnetic interference signals in the workshop.

9. Wide temperature component selection ensures stable and reliable operation under high and low temperature conditions.

10. Modular compact shell, dustproof and moisture-proof, suitable for industrial site environment.

11. Internally integrated signal summation circuit for fast calculation of deviation control variables.

12. Can turn off jitter output and optimize servo start stop smoothness as needed.

13. Original factory standard electrical parameters, no wiring changes are required for replacing old parts.

14. Compatible with closed-loop control systems for position, speed, and pressure.

15. The original circuit scheme of G122-829-001 has a low failure rate during long-term operation.

G122-829-001 is commonly used for valve control drive matching in hydraulic servo equipment and industrial precision units.

Product imag
