BOBST 704-1097-07 Communication/Signal Conditioning Board

BOBST 704-1097-07 Communication/Signal Conditioning Board

Product Details Introduction

BOBST 704-1097-07 communication signal conditioning board is used for Bosch industrial control racks to transfer and regulate various on-site sensing signals.

1. Collect the detection signal transmitted back by the photoelectric probe

2. Amplify and filter weak electrical signals to reduce interference

3. Optoelectronic isolation of strong and weak electricity to avoid circuit crosstalk

4. Complete multi specification level conversion to adapt to the motherboard

5. Relying on dedicated bus and main control board data exchange

6. Parallel multi-channel and coordinated multi-point signals

7. Real time feedback of communication conditions for board indicator lights

8. Three proof coating on circuit board, resistant to dust and ink erosion

9. Thickened gold-plated fingers, resistant to mechanical vibration and wear

10. Operating under wide temperature conditions and adapting to temperature changes in the workshop

11. Slot installation, easy disassembly and replacement operation

12. Optimize line layout to reduce signal transmission loss

13. Compatible with various photoelectric detection accessories of the same series

14. Factory performance testing is conducted item by item, with a low failure rate during operation

15. Install spare parts of the same model directly without modifying the wiring

BOBST 704-1097-07 communication/signal conditioning board serves as a signal relay hub to ensure stable and smooth signal transmission of the entire machine.

Product imag
