YASKAWA JANCD-XIO01 circuit board

YASKAWA JANCD-XIO01 circuit board

Product Details Introduction

YASKAWA JANCD-XIO01 (Yaskawa MP2000 Series Motion Controller I/O Board)

1. Brand/Model: YASKAWA (Yaskawa), Model JANCD-XIO01, dedicated digital I/O circuit board for motion control.

2. Adaptive controller: compatible with MP2000 series motion CPUs such as MP2300/MP2310/MP2400.

3. I/O points: 16 digital inputs+16 digital outputs, NPN/PNP universal input.

4. Input specification: DC24V, response time ≤ 1ms, supports drain/source wiring.

5. Output specifications: Transistor output, 0.5A per channel, maximum 4A common terminal, capable of driving small relays/solenoid valves.

6. Bus interface: MECHATROLINK-III (ML-III) high-speed motion bus, synchronization period<1ms.

7. Power supply: DC24V ± 10%, working current 1.5A, peak value 3A.

8. Environmental temperature: 0 ℃~+55 ℃, IP20 protection inside the control cabinet.

9. Synchronization performance: I/O and servo axis position synchronization processing, event driven precise control.

10. Anti interference: Industrial grade PCB design, optoelectronic isolation, anti EMI/RFI interference.

11. Installation: Standard card slot installation, plug and play, compatible with Yaskawa control cabinet slots.

12. Diagnosis: Onboard LED status indicator light for quick troubleshooting of I/O faults.

13. Structure: Green flame-retardant PCB, gold-plated contacts, reliable long-term insertion and removal.

14. Expansion: Multiple parallel I/O points can be expanded to adapt to multi axis automation equipment.

15. Application: I/O signal acquisition and output for high-speed motion control of robots, semiconductors, packaging, machine tools, etc.

JANCD-XIO01 is a high-performance synchronous I/O board for the Yaskawa MP2000 system, with fast response, strong anti-interference ability, and easy installation. It is suitable for I/O expansion and spare parts replacement in motion control applications.
