JANCD-XTUO1B Printed Circuit Board

JANCD-XTUO1B Printed Circuit Board

Product Details Introduction

YASKAWA JANCD-XTU01B (often written as XTUO1B) printed circuit board

1. Brand/Model: YASKAWA (Yaskawa) JANCD-XTU01B, belonging to the MP2000 series motion controller supporting I/O and control board.

2. Functional positioning: Servo drive/motion control core PCB, responsible for three closed-loop control of current loop, speed loop, and position loop.

3. Adaptation system: Suitable for motion CPUs and servo units such as Yaskawa MP2300/MP2310/MP2400.

4. I/O configuration: Integrated 16 digital inputs+8 digital outputs, DC24V, NPN/PNP compatible.

5. Communication interface: Equipped with RS-232/RS-485/Ethernet, supporting Modbus and other protocols, high-speed networking.

6. Power supply specifications: DC24V ± 10%, working current of about 500mA, power consumption of about 2.5W.

7. Control accuracy: Supports 17 bit high-resolution encoders, with precise positioning and fast dynamic response.

8. Protection mechanism: Built in multiple protections for overvoltage, overcurrent, short circuit, and overheating, with self diagnosis of faults.

9. Environmental adaptability: Industrial wide temperature range of 0 ℃~+55 ℃, IP20 protection, resistant to vibration and dust.

10. PCB process: FR-4 substrate, multi-layer gold-plated circuit, flame retardant solder mask, reliable insertion and extraction, long service life.

11. Installation method: Standard card slot rack mounted, plug and play, easy to maintain.

12. Status indicator: Onboard LED status light, power/operation/fault clear at a glance.

13. Redundant design: Supports parallel connection of redundant power supplies and multiple boards to enhance the reliability of continuous system operation.

14. Size and weight: about 200 × 150 × 100mm, weighing about 0.8kg, the cabinet occupies a small space.

15. Typical applications: High speed multi axis motion control scenarios such as robots, CNC machine tools, packaging machinery, semiconductor equipment, etc.

JANCD-XTU01B is a high-performance motion control PCB for the Yaskawa MP2000 system. It features precise three loop control, rich interfaces, and strong anti-interference capabilities, making it suitable for industrial automation motion control and spare parts replacement.

Product imag
