JACP-317120 power module

JACP-317120 power module

Product Details Introduction

JACP-317120 is an Yaskawa PS-01 series PLC power module, paired with CP-317 series PLC, providing stable power supply and redundant protection for control systems.

Adapt to the Yaskawa CP-317 PLC system as the core power unit.

Input: AC100-240V wide voltage, 50/60Hz, suitable for power grid fluctuations.

Output: Provides multiple stable DC outputs to meet load requirements such as CPU and I/O.

Protection: including overvoltage, overcurrent, overheating, power failure detection, automatic reset.

Efficiency: ≥ 70%, energy-saving and reducing heat generation.

Status: POWER green LED indicates clear operating status.

Installation: Terminal block wiring, M4 screw fixation, compatible with standard rack.

Environment: 0-55 ℃, humidity 5-95% RH (no condensation), industrial grade tolerance.

Safety: Compliant with UL/CSA certification, with built-in 250V/3A fuse.

Size: approximately 120 × 80 × 60mm, weight approximately 0.5-1kg, compact and easy to install.

Maintenance: Supports self diagnosis of faults and quick identification of anomalies.

Redundancy: Some configurations support redundant power supply to enhance system reliability.

Wiring: FG/SG grounding terminal, wire diameter 1.5-2.5mm ².

Specification: Hot swappable, power-off installation and maintenance are not supported.

Application: Production line control, equipment interlocking, PLC system power supply.

JACP-317120 is the stable and reliable power supply core of CP-317 PLC, ensuring the continuous operation of the control system.
