JAMSC-B1063 Input/Output Module

JAMSC-B1063 Input/Output Module

Product Details Introduction

JAMSC-B1063 is a single axis positioning control module (non universal I/O module) for Yaskawa MEMOCON-SC series PLC, used for high-precision pulse control of servo motors.

Compatible with the Yaskawa MEMOCON-SC series PLC system, it is a dedicated module for single axis servo positioning.

Core functions: Pulse train output control, absolute/incremental positioning, encoder feedback acquisition, single axis closed-loop control.

Maximum pulse output frequency: 500kHz, meeting high-speed positioning requirements.

Control axis number: 1 axis, focusing on single axis high-precision servo control.

Power supply: DC24V, input/output current is 1.2A.

Encoder input: A/B phase 90 ° phase shift, 5VDC, supports incremental encoder feedback.

Positioning mode: Supports both absolute positioning and incremental positioning modes.

Working environment: Temperature range of 0-55 ℃, humidity range of 5-95% RH (no condensation); Storage -20~75 ℃.

Insulation performance: Terminal/module shell insulation resistance>1000M Ω (50VDC).

Installation: DIN rail installation, with a plug-in life of ≥ 100 times.

Anti interference: Complies with the IEC 61000-4 industrial EMC standard and adapts to the electromagnetic environment in the workshop.

Size: approximately 75 × 125 × 30mm, weight approximately 0.3kg.

Application scenarios: CNC machining, precision assembly, testing equipment, small robot joint positioning.

Interface: Pulse output (CW/CCW or PULSE/DIR), encoder feedback, enable/alarm and other control signal terminals.

Protection: overcurrent, overvoltage, and overheating protection to ensure the safety of modules and servo systems.

JAMSC-B1063 is the core module of the Yaskawa MEMOCON-SC system for achieving high-precision single axis servo positioning.

Product imag
