CP-317/217 IF servo drive communication module

CP-317/217IF is an Yaskawa CP-9200SH series servo/motion control dedicated high-speed communication module used for real-time data exchange between controllers and servo drives. It belongs to the Yaskawa high-end motion control bus module.

Brand and model: Yaskawa, CP-317/217IF, CP-9200SH series

Core positioning: Servo driven communication interface, realizing high-speed real-time linkage between controller and servo

Adaptation system: Yaskawa CP series, MP series controllers (MP920, MP2300, etc.)

Communication type: High speed serial communication, RS-422/485 differential interface, long-distance stable transmission

Transmission distance: up to 1200 meters, suitable for long-distance production line servo networking

Protocol support: Yaskawa dedicated servo communication protocol, compatible with Modbus and CANopen

Transmission rate: up to 1Mbps, ensuring real-time servo commands and feedback

Power supply: DC 24V, power consumption ≤ 10W, industrial grade low-power design

Physical interface: D-Sub 9-pin/terminal block, compatible with servo drive standard communication port

Size: approximately 114 × 100 × 70mm, weight approximately 0.5kg, compact module

Environment: -20 ℃~+60 ℃, 5%~95% RH, no condensation, wide temperature industrial grade

Function: Read and write servo parameters, issue position/speed/torque commands, collect encoder feedback

Diagnosis: Communication status monitoring, fault alarm, link self-test, convenient for operation and maintenance

Application: High precision servo control scenarios for machine tools, robots, assembly lines, packaging equipment, etc

Status: Discontinued, the market mainly consists of second-hand/refurbished/repaired spare parts

CP-317/217IF has become the core communication hub of Yaskawa's high-end servo system with high-speed stability, long-distance transmission, and strong compatibility.

Product imag
