Toshiba DO334 Controller Module

Toshiba DO334 Controller Module

Product Details Introduction

Toshiba DO334 is a high-density absorption DC output module for Toshiba PROSEC T3/T3H and V series controllers. It provides 32 output points with a single slot width and is suitable for high-frequency switches and complex industrial environments.

The output type is absorption transistor, with a rated load voltage of 24VDC and a working voltage range of 20.4-28.8VDC.

32 point discrete output, maximum 0.1A per point, total module current ≤ 3.2A, 16 points/common terminal.

Response time: OFF → ON ＜ 0.5ms, ON → OFF ＜ 1.0ms, suitable for high-speed rhythm.

Optocoupler isolation, anti electromagnetic interference, suitable for working conditions such as motors and frequency converters.

When the leakage current is ≤ 0.1mA (at 24VDC), reduce standby power consumption and misoperation.

High density multi pin connector on the front panel, convenient wiring, reduces wiring errors.

Each point is equipped with a status LED, and the module comes with a running indicator light for real-time diagnosis.

Built in back electromotive force protection, suitable for inductive loads such as solenoid valves and relays.

Working temperature 0-55 ℃, humidity 5% -95% non condensing, suitable for workshop environment.

Anti vibration and anti impact design, supporting 7 × 24-hour continuous operation.

Fully compatible with the T series backplane, the high-speed internal bus ensures low latency output refresh.

Compatible with T-PDS programming tools, efficient configuration and debugging.

Supports direct I/O access and batch refresh, with high data exchange efficiency.

Single module has low power consumption, saving overall system energy consumption.

Widely used in high-speed and continuous production scenarios such as automobile manufacturing, water treatment, semiconductors, food and beverage.

Toshiba DO334 has become the core output component of T3/T3H and V series controllers due to its high-density, high response, strong anti-interference, and easy maintenance characteristics, and is stably adapted to various industrial automation scenarios.

Product imag
