EMERSON 3A99158G01 I/O interface board

EMERSON 3A99158G01 I/O interface board

Product Details Introduction

EMERSON 3A99158G01 I/O interface board

EMERSON 3A99158G01 (also known as 4PCRL1) is a local I/O interface board for Emerson Ovation DCS systems, providing high-speed and highly reliable signal interaction between the system and on-site sensors/actuators, suitable for key process control scenarios such as power, chemical, and energy.

Specially designed for Emerson Ovation distributed control systems, compatible with Ovation backboards and system architecture.

The full name of the model is 4CCRL1, assembly number 3A99158G01, originally belonging to the Westinghouse Electric product line.

Provide 2 independent sensor signal inputs, support eddy current/Hall effect sensors, input voltage 0~-27.3V DC.

Built in 2-channel -26.75V DC sensor power supply, compatible with sensors such as epro PR6423 and PR9376.

Integrate 2 TTL pulse outputs for speed/displacement monitoring signal feedback.

The front panel is equipped with an SMB test interface, which can directly monitor input signals (signal attenuation 0.15 times).

Supports Modbus RTU/RS-485 communication, compatible with fieldbus and third-party devices.

Power supply 24V DC (wide voltage 12-24V DC), power consumption ≤ 15W, suitable for industrial distribution.

Working temperature: * * -20 ℃~+60 ℃ *, storage: -40 ℃~+85 ℃, suitable for harsh industrial environments.

Standard Ovation card installation, compatible with system backboards, supports multi card parallel expansion.

Electrical isolation between channels, strong resistance to electromagnetic interference (EMI), ensuring signal integrity.

Built in fault diagnosis and status indication, quickly locate channel abnormalities.

Support hot swapping, online replacement does not affect system operation.

Industrial grade components and PCB design to meet 24/7 continuous operation requirements.

Compliant with international safety certifications such as CE and UL, and compatible with global industrial standards.

The EMERSON 3A99158G01 I/O interface board, with high reliability signal conditioning, strong anti-interference and system compatibility, has become the core interface unit for on-site data acquisition and control output of Ovation system, ensuring stable signal transmission for key industrial processes.

Product imag
