Siemens 6AV3617-1JC20-0AX1 Touch Panel

Siemens 6AV3617-1JC20-0AX1 Touch Panel

Product Details Introduction

Siemens 6AV3617-1JC20-0AX1 Touch/Operation Panel (15 features)

Belonging to the Siemens SIMATIC HMI OP 17/DP series, it is a monochrome text/graphic operation panel with a non color touch screen.

Adopting LED backlit monochrome LCD, supporting 4 × 20 or 8 × 40 character display, presenting industrial parameters and status clearly.

Equipped with 24 film function keys, directional keys, and numeric keys, the operation is stable, dustproof, and durable, suitable for industrial sites.

Built in 256 KB user available memory (Flash+RAM), capable of storing interface programs and configuration data.

Communication interface: MPI/PROFIBUS-DP, up to 1.5 Mbps, seamlessly integrated with S7/M7 series PLCs.

Power supply: 24 V DC (± 20%), rated current 0.34 A, power consumption of approximately 10 W, compatible with industrial standard power supply.

Protection level: IP65 front panel, IP20 back panel, waterproof and dustproof, suitable for embedded installation in cabinets.

Supports PROFIBUS-DP slave mode and can be directly connected to the DP network to achieve remote monitoring and data exchange.

Compatible with SIMATIC S7-300/400, M7, 505 series PLCs, with strong versatility.

Support basic HMI functions such as alarm display, event recording, parameter setting, trend curve, etc.

Installation size: 240 mm × 204 mm, standard embedded installation, weight approximately 0.96 kg.

Working temperature range of 0-50 ° C, suitable for wide temperature environments in industrial sites, and stable long-term operation.

Equipped with CE, UL, FM, and EX Zone 2/22 certifications, in compliance with global industrial safety standards.

The product has been discontinued, and the market mainly consists of second-hand, refurbished, and original spare parts for the maintenance and replacement of old systems.

Specially designed for traditional industrial control scenarios, with simple operation, high reliability, and low maintenance costs, it is the preferred HMI upgrade for old production lines.
