Siemens 6AV6545-0BC15-2AX0 touch screen panel (15 features)

Belonging to the Siemens SIMATIC HMI TP 170B series, it is a 5.7-inch color STN touch panel designed for small and medium-sized industrial HMI applications.

Screen specifications: 5.7-inch STN color LCD with a resolution of 320 × 240 (QVGA), supporting 256 color display and clear image.

Touch type: Industrial grade analog resistive touch, sensitive response, precise positioning, supports glove wearing operation.

Communication interface: Integrated MPI/PROFIBUS-DP dual protocol interface, up to 1.5Mbps, seamless integration with PLCs such as S7-300/400.

Expansion interface: Comes with RS-232/printer interface, supporting data printing and external device expansion.

Storage Expansion: Built in CF card slot, can be used for project backup, program transfer, and data storage.

User Memory: Onboard 2MB project memory (Flash+RAM) to meet interface and logic program storage requirements.

Power supply: 24V DC (± 20%), industrial standard power supply, suitable for on-site power environment.

Protection level: IP65 front panel, IP20 back panel, dustproof and waterproof, suitable for embedded installation in cabinets.

Configuration software: Supports ProTool/Lite V5.2+SP2 configuration, drag and drop design, fast to use, and efficient deployment.

Functional features: Built in alarm system, trend curve, parameter setting, multilingual switching (5 types), meeting basic monitoring needs.

Compatibility: Compatible with Siemens and third-party devices such as S7-200/300/400, 505, WinAC, SINUMERIK, etc.

Environmental adaptation: Working temperature range of 0-50 ° C, resistant to vibration and oil stains, suitable for harsh working conditions in industrial sites.

Installation: Standard embedded installation, compact size, weighing approximately 1.3kg, saving cabinet space.

Product status: discontinued. The market mainly consists of second-hand, refurbished, and original spare parts, specifically designed for maintenance and replacement of old TP170B systems.
