Product Details Introduction

BUR622-16-2 is a ballast control unit (braking/energy consumption control module) for Baumuller servo drive systems in Germany, used for DC bus energy consumption braking, overvoltage protection, and energy release management of servo systems.

The brand is Baumuller from Germany, which is compatible with its servo drive and control system.

Core function: Control external braking resistors, discharge servo bus feedback energy, and stabilize bus voltage.

Belonging to the BUR series brake control module, the complete model is BUR622-16-2 (commonly suffix -000).

Suitable for 400V servo drive system, handling high voltage and regenerative energy of DC bus.

16A level braking current output, matched with medium and high-power servo motor braking conditions.

Equipped with a triple safety mechanism of overvoltage detection, overcurrent protection, and resistance overload monitoring.

Support PWM chopper control, accurately adjust braking power and release speed.

Industrial grade wide temperature range: -25 ° C to+70 ° C, suitable for harsh workshop environments.

Standard rail installation, compact structure, suitable for Baumuller drive cabinet layout.

Built in temperature monitoring to prevent the brake resistor from overheating and burning out.

Support fault status output (relay/transistor) and connect to the system safety circuit.

24V DC auxiliary power supply, low power consumption, long-term stable operation.

Electrical isolation design, strong anti-interference, ensuring the safety of the drive system.

Suitable for high inertia scenarios such as injection molding machines, machine tools, printing machinery, lifting equipment, etc.

As an original spare part, used for Baumuller system maintenance, upgrade, and replacement.

BUR622-16-2, with reliable busbar energy management, precise braking control, and comprehensive protection, has become a key module in the Bao Miller servo system to ensure the safe and stable operation of high dynamic and high inertia equipment.

 Product imag
