OADM 20I6572/S14F sensor

OADM 20I6572/S14F sensor

Product Details Introduction

OADM 20I6572/S14F is a high-precision laser ranging sensor from Baumer Platz, Switzerland. It focuses on analog output and short-range precision measurement, and is suitable for high-precision positioning, thickness detection, and displacement measurement scenarios in industrial automation.

The brand is Baumer, Switzerland, and belongs to the OADM series of laser ranging sensors.

Measuring range of 50mm to 300mm, suitable for short distance high-precision measurement requirements.

The light source adopts a pulsed red laser diode with a wavelength of 650nm and a laser level of Class 2.

The measurement resolution is as high as 4 μ m, with a linear accuracy of ± 0.25mm, and the measurement accuracy is extremely high.

The response and release time are both less than 0.9ms, which meets the requirements of high-speed dynamic detection scenarios.

The output signal is a dual-mode analog: 4-20mA current and 0-10V voltage, compatible with mainstream control systems.

Equipped with 1 PNP alarm output, it can provide feedback on abnormal and fault states.

Supply voltage 12-28V DC, maximum power consumption 100mA, suitable for industrial DC power supply.

The interface is an 8-pin rotatable M12 connector, with flexible installation and wiring.

Supports both button and external self-learning calibration methods, making debugging convenient.

Protection level IP67, dustproof and waterproof, suitable for industrial environments with high dust and humidity.

The working temperature ranges from 0 ° C to+50 ° C, with temperature compensation and a temperature drift of less than 0.03%/K.

Equipped with dual electrical protection for short circuit and reverse polarity, the module has strong stability.

Dual LED indicator lights: green indicates power on, red indicates lens contamination or malfunction.

Widely used in precision positioning, thickness measurement, electronic component testing, automated production lines and other fields.

OADM 20I6572/S14F has become the core sensor for precision detection and high-precision displacement control scenarios due to its ultra-high measurement accuracy, fast response, stable analog output, and reliable industrial protection.

 Product imag
