3HAC17326-1/02 Robot servo motor

3HAC17326-1/02 is a Type-B M26 AC servo motor specifically designed for ABB IRC5 control systems. It provides power for the 1-3 axes of the IRB2400 series robots and is the core executing component for robot joint movements.

Brand affiliation: ABB robot, 3HAC series dedicated servo motor

Complete model: 3HAC17326-1/02, type code M26 Type-B

Compatible models: ABB IRB2400 industrial robot (1-3 axes)

Adaptation system: IRC5 series robot control cabinet

Motor type: Permanent magnet synchronous AC servo motor

Rated voltage: 200V AC

Rated current: 2.4A

Feedback configuration: Built in high-precision encoder, supporting closed-loop position control

Brake function: Integrated electromagnetic brake, power-off lock shaft ensures safety

Physical specifications: approximately 263 × 58 × 28mm, weight approximately 4.3kg

Product status: Original factory shutdown, mainly focused on refurbished/inventory spare parts

Origin: United States

Application scenarios: IRB2400 robot joint drive, point motion, trajectory control

This motor is characterized by high torque density, low inertia, and fast response, ensuring precise and stable robot motion, and is a key spare part for IRB2400 system maintenance.

 Product imag
