Product Details Introduction

3HAC14550-2/09A Robot External Axis Drive

3HAC14550-2/09A is a single axis servo drive unit specifically designed for ABB IRC5 control systems, providing high-precision closed-loop control for robot external axes (tracks, rotary tables, positioners, etc.) and serving as the core power component for external axis expansion.

Brand affiliation: ABB robot, 3HAC series external axis dedicated drive

Complete model: 3HAC14550-2/09A, basic model 3HAC14550-2

Adaptation system: ABB IRC5 series robot control cabinet

Core function: Single axis servo motor closed-loop control, driving precise positioning and motion of external axes

Control object: robot external axis (linear track, rotary table, positioner, etc.)

Interface type: Dedicated servo bus, supporting encoder feedback and brake control

Power supply specifications: Suitable for industrial three-phase AC power supply, compatible with robot control cabinet power supply

Protection function: Multiple protections for overvoltage, overcurrent, overheating, and encoder abnormalities

Physical specifications: Compact module, compatible with IRC5 control cabinet backplane installation

Weight: Approximately 3.17kg

Product status: The original factory has ceased production, with a focus on new inventory and refurbished spare parts

Origin: Ireland

Application scenarios: robot track extension, linkage of positioners, multi axis collaborative operation

This driving unit ensures synchronization between the outer axis and the robot body, enhances the system's operating range and flexibility, and is a key spare part for the expansion of the outer axis of the IRC5 system.

 Product imag

3HAC14550-2 09A.webp.jpg
