GIDINGS&LEWIS NSM2302 B24 servo motor

GIDINGS&LEWIS NSM2302 B24 servo motor

Product Details Introduction

GIDINGS&LEWIS NSM2302 B24 servo motor

Product Overview

Giddings&Lewis NSM2302 B24 is a high-performance AC servo motor, mainly used in applications that require high precision and high dynamic response, such as CNC machine tools, industrial robots, and automated production lines. This motor is used in conjunction with G&L servo drives (such as the M.1015 series) to form a complete servo system, ensuring precise and stable motion control.

Technical characteristics (typical parameters)

Motor type: AC Servo Motor

Main functions:

Provide precise speed, position, and torque output

Closed loop control with servo drive, supporting high-precision feedback adjustment

Structural design:

Compact design, suitable for installation of devices with limited space

High performance permanent magnet rotor enhances dynamic response capability

Feedback method: Built in encoder/parser to ensure closed-loop control accuracy

Operational performance:

High torque density, low inertia design

Quick start stop and precise positioning

Protection function:

Over temperature protection, overload protection, insulation design, suitable for industrial environments

Environmental conditions:

Working temperature: 0 ° C~40 ° C

Humidity:<90%, no condensation

Application field

Numerical Control Machine Tool (CNC)

Drive spindle or feed axis, supporting high-precision machining such as turning, milling, grinding, etc.

Industrial automation production line

Applied to assembly, handling, and testing equipment to improve production efficiency and consistency.

robot system

As a joint driven motor, it achieves flexible, fast, and precise motion control.

Packaging and Printing Machinery

Used for feeding, tension control, and synchronization systems to ensure stability during high-speed operation.

Electronic and semiconductor manufacturing equipment

Suitable for high-precision applications such as surface mount machines, testing machines, and wafer handling equipment.

Testing and experimental platform

Provide reliable driving capability in motor performance testing benches and R&D experimental equipment.

Product imag
