GIDINGS&LEWIS 503-19029-00 Execution Control Board
- Goods status： new/used
- Delivery date: stock
- The quality assurance period： 365 days
- Phone/WhatsApp/WeChat：+86 15270269218
- Email：stodcdcs@gmail.com
- Tags：
- Get the latest price：Click to consult
GIDINGS&LEWIS 503-19029-00 Execution Control Board
Product Details Introduction
Product Overview
GIDINGS&LEWIS 503-19029-00 Execution Control Board is a core control module used in industrial automation and numerical control systems. It is mainly responsible for receiving instructions from the upper controller and accurately controlling servo drives, stepper motors, hydraulic valves, or other actuators to achieve the start, stop, direction, and speed adjustment of actions. This control board is an important component that ensures the precise operation and high efficiency of automation equipment.
Technical parameters (typical)
Control type: pulse output/direction control/servo drive control
Input interface: receives instruction signals from the main control CPU or logic controller
Output interface: Supports multi-channel execution signal output, can directly drive drivers or repeaters
Signal level: compatible with industrial standard levels (such as 24VDC)
Response speed: High speed pulse output, meeting high dynamic response requirements
Protection mechanism: Overload, short circuit, overvoltage, and signal abnormality protection
Installation method: Modular plug-in board design, easy to expand or replace in the control system
Status indication: LED displays the working status of each channel for easy debugging and maintenance
Application scenarios
CNC machine tool
Control the feed axis, spindle, and auxiliary actuator to achieve high-precision machining.
Automatic production line
Drive assembly, conveying, and sorting equipment to achieve synchronized process actions.
industrial robot
Control the joints or end effectors of the robotic arm to achieve precise movements.
Packaging and Printing Machinery
Drive feeding, cutting, packaging and other actions to ensure consistent rhythm.
textile machinery
Control the winding, tension, and feeding actions to ensure product quality and production efficiency.
Experimental and testing equipment
Used for servo control experimental or testing platforms to achieve multi-channel precise motion control.
Product imag
