MAGNETEK EDB4040EH dynamic braking resistor

MAGNETEK EDB4040EH dynamic braking resistor

Product Details Introduction

product overview

MAGNETEK EDB4040EH is an industrial grade dynamic braking resistor designed for energy absorption and consumption in frequency converters and drive systems. Its main function is to release the energy feedback from the motor in the form of thermal energy during rapid deceleration or braking of the motor, thereby protecting the driving equipment and extending the system life.

Product Features

High power absorption capacity: able to withstand high-energy impacts during the braking process of the frequency converter, quickly dissipating feedback energy.

Excellent thermal management design: using high-temperature resistant materials and reasonable heat dissipation structure to ensure long-term stable operation.

Compact and sturdy structure: easy to install inside the control cabinet, occupying small space, suitable for harsh industrial environments.

Multiple resistance values and power levels: can be selected according to system requirements to meet different braking requirements.

High reliability and safety: Complies with industrial standards and has good resistance to vibration and impact.

application area

Variable frequency drive system

Widely used in fans, water pumps, conveyors and other equipment driven by AC frequency converters to achieve dynamic braking function.

Cranes and handling equipment

Used for rapid deceleration and stopping of bridge cranes, gantry cranes, gantry cranes, etc., to protect mechanical safety.

Metallurgy and Mining Machinery

Adapt to the braking requirements of high inertia loads, ensuring equipment stability and safety.

Textile, printing and packaging machinery

Ensure smooth braking of high-speed machinery when stopped, improve production efficiency and product quality.

Elevators and lifting platforms

Realize smooth braking and improve personnel and equipment safety.

Product imag
