Magnetek 1X00024H01 power module

Magnetek 1X00024H01 power module

Product Details Introduction

1、 Product Overview

Magnetek 1X00024H01 is an industrial grade power module, typically labeled as WH1-2FF, primarily used in Emerson/Westinghouse's Ovation distributed control system (DCS). This module provides continuous and reliable power support for various modules in the control system by converting AC input into stable DC output.

Main technical parameters:

Input voltage: 100-240 VAC, 50/60 Hz

Input current: approximately 8-12 A (depending on input voltage)

Output voltage: 24   VDC

Output power: up to approximately 500   W

Application type: AC to DC stabilized power module

2、 Application Fields

Power plant control system

Widely used as the main control power supply for Ovation control systems in thermal, hydroelectric, nuclear and other power plants.

Provide 24V stable DC output to ensure long-term stable operation of control modules and I/O modules.

Water Treatment and Environmental Protection Engineering

In sewage treatment plants and water treatment plants, power is supplied to the signal conditioning module and actuator in the process control system.

Adapt to the long-term uninterrupted operation requirements of industrial sites.

industrial automation control system

Applied to large-scale DCS control systems, providing isolated power supply for process monitoring units, communication modules, and logic boards.

Ensure the continuity and reliability of process data collection and control logic.

Petrochemical, steel and heavy industry

In industries with complex processes and high environmental requirements, provide clean and stable power supply guarantees for key control nodes.

Maintenance and spare parts replacement market

Although it is a discontinued model, it is still used as an important replacement component in equipment refurbishment and old system maintenance due to its widespread use in in-service systems.
