ATLAS COPCO TC52S-I Tool Controller

ATLAS COPCO TC52S-I Tool Controller

Product Details Introduction

1、 Product Overview

TC52S-I is a fastening tool controller launched by Atlas Copco, belonging to the high-performance model of the TC5000 series, dedicated to driving and managing industrial electric screwdrivers, servo tools and other tightening equipment. The "I" in the model indicates that it is equipped with PROFINET IO (Industrial Ethernet) communication interface, which facilitates integration with various PLCs and automation systems.

This controller is used in assembly environments with high precision, high tempo, and multi program requirements, and is the core control component of automated tightening systems.

2、 Core functions and technical parameters

Product model: TC52S-I

Control functions: torque control, angle control, composite process control

Communication interface: PROFINET IO

Compatible tools: Atlas Copco electric servo tools, fastening shafts, multi axis assembly systems

Program Management: Supports up to hundreds of fastening programs

Real time monitoring: data collection, process monitoring, error alarms

Functional support:

Advanced features such as multi-stage control, soft start, virtual bolt, etc

Data traceability and analysis interface

Integrate with MES, PLC, HMI and other systems

3、 Typical application areas

1. Automotive manufacturing assembly line

Applied to workstations that require high consistency and traceability in body, chassis, engine assembly, etc

Realize high-precision control and process visualization of bolt tightening

2. Mechanical and industrial equipment manufacturing

Complex fastening process management under multi axis control

Meet the installation requirements of high torque and complex structural components

3. Electronics and Home Appliances Industry

Fine electronic component screw control to prevent over tightening or over tightening

Support flexible assembly requirements and small batch switching

4. Aerospace and Rail Transit

Used for highly controllable and traceable fastening tasks

Support high-level quality standards and safety standards

Product imag
