Tokyo Electron 3208-000173-13 Interface Module

Tokyo Electron 3208-000173-13 Interface Module

Product Details Introduction

Tokyo Electron (TEL) 3208-000173-13 Interface Module - Detailed Explanation of Product Application Fields

1. Internal signal and control communication hub of semiconductor equipment

Core function: The 3208-000173-13 interface module serves as a communication bridge between the control system and the execution module, enabling the transmission and conversion of various signals (such as analog, digital, serial communication, etc.).

Application value: It ensures that commands from the upper level controller can be accurately received and responded to by the lower level executing mechanism, while feeding back device status information to the main control system.

2. Inter module connection and expansion platform

System integration: The interface module supports connecting multiple control units, power modules, sensors, and actuators into a unified system for centralized management.

Structural advantage: Modular design is easy to expand or upgrade, and can quickly adjust the system architecture according to changes in device configuration.

3. Support multiple industrial communication protocols

Communication capability: May support industrial communication standards such as RS-232/RS-485, Ethernet, CAN, I ² C, etc., to achieve high-speed and stable data exchange.

Strong adaptability: It is compatible with different types of controllers (PLC, industrial computer, customized control card) and field devices, and can build a multi-level distributed control network.

4. Typical application scenarios

Interface modules for main control systems such as lithography machines, CVD, Etcher, etc.: used to connect the main control board with cavity control, motor drive, temperature control, gas flow control, and other units.

Signal acquisition and status feedback system: Collect the operating status, fault signals, temperature, pressure, position and other parameters of each part of the equipment and transmit them back to the main control.

User interface and human-computer interaction interface: Connect touch screens and operation panels to achieve local control and remote debugging of devices.

Product imag
