TEL Tokyo Electron 5044-000158-11 Controller Module

TEL Tokyo Electron 5044-000158-11 Controller Module

Product Details Introduction

Product Name: 5044-000158-11 Controller Module

Manufacturer: Tokyo Electron Ltd

Product Type: Device Controller Module

1、 Product Overview

5044-000158-11 is a specialized controller module used in Tokyo Electron semiconductor manufacturing equipment, typically serving as a key control core for subsystems or functional areas. It has multiple functions such as signal acquisition, control execution, data communication, and status management, and is commonly used to achieve closed-loop control in automated process flows.

2、 Main functions

Logic control function

Execute fixed or programmable control logic to process control signals from sensors, actuators, or main control systems.

Data acquisition and signal processing

Receive and process analog or digital input signals (such as temperature, pressure, position, switch status, etc.).

Actuator driver

Control the actions of executing components such as solenoid valves, motors, and heating units, including functions such as start stop, speed regulation, and positioning.

communication function

High speed data exchange with the main controller, upper computer or other modules, interface forms may include RS-232/485, Ethernet, CAN bus, etc.

System monitoring and fault alarm

Real time monitoring of system operation status, providing alarm outputs in the form of LED or digital signals.

Product imag
