TEL Tokyo Electron 1181-000253-1B Control PCB Card

TEL Tokyo Electron 1181-000253-1B Control PCB Card

Product Details Introduction

Product Name: 1181-000253-1B Control PCB Card

Manufacturer: Tokyo Electron Ltd

Product type: Control PCB Card

1、 Product Overview

1181-000253-1B is a dedicated control PCB (Printed Circuit Board) card used for module level control functions in Tokyo Electron semiconductor equipment, which is used to implement functions such as logic control, signal management, power allocation, or interface communication. It usually exists as the control core module of equipment subsystems such as vacuum, heating, handling, etc.

2、 Main functions

Logic Control and Execution

Equipped with control chips (such as MCU, FPGA or CPLD), execute preset actions according to the process program.

I/O signal processing

Receive input signals from sensors, switches, etc., and output control commands to actuators (such as solenoid valves, motors, heaters).

Communication interface conversion

Support communication with the main control system, such as serial port, TTL, I ² C, CAN, or TEL proprietary protocols.

Power regulation and protection

Onboard power supply stabilizing module or filtering unit ensures stable power supply to all components.

3、 Applicable equipment system (typical application)

This card is widely used in the key control submodules of the following Tokyo Electron devices:

Etcher etching equipment

CVD/PVD thin film deposition system

Coater/Developer coating and developing equipment

Robot handling systems (such as wafer handling, lifting platforms, etc.)

Chamber control unit or gas distribution system

Product imag
