KLA Tencor 710-611867-000 Image Board

KLA Tencor 710-611867-000 Image Board

Product Details Introduction

The KLA Tencor 710-611867-000 Imaging Board is a key image acquisition and processing module in KLA Tencor's high-end semiconductor testing equipment. It is responsible for receiving image signals from optical sensors or cameras, performing preliminary processing and data transmission, and providing high-quality image data support for subsequent defect detection and analysis.

1、 Basic Product Information

Model: 710-611867-000

Type: Imaging Board

Series: KLA Tencor 710 Series

Main functions: High performance image signal acquisition, primary image processing, and data interface management

2、 Main functions and features

Function Description

Image signal acquisition is connected to optical sensors such as CCD and CMOS to capture high-resolution image signals in real time

Image preprocessing includes noise filtering, gain adjustment, image enhancement, etc., to improve image quality

High speed data transmission transmits image data to the main processing unit through high-speed buses (such as PCIe, dedicated high-speed interfaces)

Synchronize control with scanning platforms, laser sources, and other equipment to ensure accurate image acquisition timing

Multi channel support supports multiple image signal inputs, enabling multi-sensor collaborative acquisition

Stable and reliable industrial grade design, suitable for high-frequency operation requirements in complex semiconductor manufacturing environments

3、 Application Fields

Surface defect detection of wafers

Collect high-resolution surface images for defect recognition, localization, and classification.

Automatic Optical Inspection (AOI) System

Realize fast and high-quality image acquisition, support high-speed online detection.

Optical measurement equipment

Provide imaging data foundation, assist in morphology analysis, thickness measurement and other functions.

Electron Beam (e-beam) Imaging System

In electron beam detection equipment, it is used to collect secondary electron images or other signals.

Product imag
