EATON PL9-C20-2 Miniature Circuit Breaker

EATON PL9-C20-2 Miniature Circuit Breaker

Product Details Introduction

product name

EATON PL9-C20-2 Miniature Circuit Breaker

product overview

EATON PL9-C20-2 is a miniature circuit breaker designed specifically for low-voltage AC circuits, belonging to the Eaton PL9 series. It is mainly used for overload and short circuit protection of circuits, ensuring the safe operation of electrical equipment and circuits. This circuit breaker adopts a C-type trip curve and is suitable for general lighting, socket, and motor protection. It is widely used in residential, commercial, and industrial fields.

Main technical parameters

Rated current (In): 20 amperes

Number of poles: 2 poles

Rated voltage: 230/400 volts alternating current (AC)

Release characteristics: C-type release curve, instantaneous release, suitable for general loads

Rated short-circuit breaking capacity: usually 6kA or 10kA, please refer to the product specifications for details

Installation method: 35mm standard guide rail installation, easy to install and maintain quickly

Compliant with standards: Compliant with IEC/EN 60898-1 standard, meeting international safety and performance requirements

Environmental adaptability: Wide working temperature range, suitable for various installation environments

Product Features

Efficient protection: able to quickly disconnect overload and short-circuit currents, preventing damage to circuits and equipment.

Compact design: saves distribution box space and facilitates multi module installation.

Easy to operate: The switch handle is intuitive, making it convenient for users to identify the switch status.

Strong stability: High quality manufacturing ensures long-term stable operation.

Multi purpose application: Suitable for various types of loads, including lighting, sockets, and low-power motors.

Product imag
