KLA Tencor 770-809195-000 Image Processor Module

KLA Tencor 36-0201 Main Interface Board

Product Details Introduction

1、 Basic Information

Product model: 770-809195-000

Manufacturer: KLA Tencor

Product type: Image Processor Module

Main purpose: Used in semiconductor testing equipment for high-speed processing and analysis of collected image data

2、 Function Description

Real time high-speed image data processing

Support complex image analysis algorithms such as defect detection, image enhancement, filtering, etc

Provide high bandwidth data transmission interface to ensure image processing efficiency

Collaborate with other modules of the detection equipment to improve overall detection performance

Supports multiple image input formats and interface standards

3、 Technical parameters (reference)

Processing capability: High performance image processing chip, supporting multi-threaded parallel computing

Interface type: High speed data interface (such as Camera Link, LVDS, or dedicated bus interface)

Input format: Multiple digital image formats supported

Working voltage: Depending on the equipment specifications, it is generally 12V or 24V DC

Working temperature range: industrial grade temperature adaptation, usually from 0 ℃ to+60 ℃ or wider

Size specifications: comply with the internal installation requirements of the equipment, and the specific size depends on the equipment design

4、 Application Fields

Semiconductor wafer defect detection system

Electron microscope image acquisition and processing

Precision optical testing equipment

Other industrial inspection systems that require high-speed image processing

5、 Advantages and Characteristics

High speed parallel processing capability enhances detection speed

Multi functional image algorithm support enhances detection accuracy

Good system compatibility, easy to integrate into existing devices

Industrial grade design, suitable for harsh working environments

Product imag
