Chromalox 3204-71001 Temperature Controller

Chromalox 3204-71001 Temperature Controller

Product Details Introduction

1、 Basic Information

Product model: Chromalox 3204-71001

Product type: Temperature controller (thermostat)

Series affiliation: Chromalox 3204 series (OEM customized model)

Application areas: Industrial heating systems (such as heaters, electric furnaces, heat treatment equipment, extrusion equipment)

2、 Core functions

Control type:

PID control (with automatic tuning function)

Optional ON/OFF control

Support dual output control mode for heating/cooling

Display mode:

Double row 4-digit digital tube LED display

Upper row: Temperature measurement (PV)

Lower row: Set temperature (SV)

Input type (compatible with multiple sensors):

Thermocouples (J, K, T, N, R, S)

RTD（Pt100）

Linear voltage/current input (0-10V, 4-20mA, depending on version)

Output type (depending on the "71001" suffix configuration):

Output 1: Relay output (controlling heater)

Output 2: Optional relay/SSR drive/analog output (for cooling or alarm)

Alarm output: supports configurable logic such as high and low limit alarms, deviation alarms, etc

Optional: with remote setting input and communication function (RS485 Modbus)

3、 Electrical and structural parameters

Power input: 85264 VAC, 4763Hz

Installation method: disk mounted, standard DIN panel size

Panel size: 48mm x 48mm (1/16 DIN)

Panel opening: 45 x 45 mm

Front panel protection level: IP65 (dustproof, waterproof, splash proof)

Working temperature range: 0 ° C~50 ° C

Storage temperature range: -20 ° C~70 ° C
