Product Details Introduction

Siemens 6SL3120-1TE24-5AA3 is a Single Motor Module (SMM) in the Siemens SINAMICS S120 series, mainly used for high-performance servo and drive control systems, widely used in automation fields such as machine tools, printing machinery, packaging equipment, etc. that require precise motion control.

1、 Product Overview

Project Description

Product model 6SL3120-1TE24-5AA3

Product Name SINAMICS S120 Single Motor Module (SMM)

SINAMICS S120 series

Functional servo drive single motor control module

Application areas: high-performance servo drive systems, mechanical automation, motion control

2、 Technical parameters

Parameter Description

Input voltage 3 × 380-480 V AC

Rated current 9 A

Rated power 4 kW

Rated frequency 0-500 Hz (modulation frequency range)

Control method: Vector Control

Interface type PROFINET/PROFIBUS (communication module required)

Cooling method: air cooling or forced cooling

Size approximately 186 x 160 x 300 mm (width x height x depth)

Weight approximately 5 kg

Product imag
