193X257AAG01 power board

193X257AAG01 power board

Product Details Introduction

The GE 193X257AAG01 power board is a critical power module in the GE (General Electric) 193X series industrial control systems. This board is typically used as the power supply core for DC speed controllers or industrial control systems, providing stable and reliable voltage and current support for multiple submodules in the control system.

1、 Product basic information:

Product model: 193X257AAG01

Type: Power Supply Board

manufacturer: GE Industrial Systems

Series affiliation: GE 193X modular control platform

Main function: Provide multi-channel stable power supply to ensure the normal operation of the control system

2、 Functional features:

Multi channel power output

Provide DC power outputs of different voltage levels (such as ± 15V, 5V, etc.) to power modules such as signal processing, amplifiers, and logic control.

Overcurrent and Overvoltage Protection

Built in protection mechanism to prevent system damage due to overload, short circuit and other issues, improving the operational safety and lifespan of the entire system.

High stability and low noise

The output voltage has small ripple and high stability, making it suitable for use in precision signal processing circuits to ensure system accuracy and reliability.

Good compatibility

Designed for use in GE's speed control system, especially in conjunction with GE's 193X drive series (such as DC300 system).

3、 Typical application areas:

DC Drive Systems

As the core power supply module of the speed controller, it drives the control board, signal processing board, and feedback circuit.

Power plant control system

Used in control equipment for steam turbines and gas turbines to supply power to control and signal modules.

Automation Control in Metallurgy and Steel Industry

Provide stable power supply for the rolling mill, motor control, and speed regulation system.

Chemical and Paper Industry

Used for large-scale continuous industrial process control systems, providing continuous and stable power support.

Railway traction system

Used in locomotives or traction systems to ensure power supply for various control units.

Product imag
