DS215UCVBG3A control module

DS215UCVBG3A control module

Product Details Introduction

GE DS215UCVBG3A Control Module

product overview

GE DS215UCVBG3A is an industrial control module in the General Electric Mark V series, used for gas and steam turbine control systems. It is one of the core components of this series of control systems, responsible for key tasks such as logic processing, communication management, signal acquisition, and control output.

major function

Control logic processing

The module is equipped with a built-in processor that is responsible for receiving internal and external input signals of the system, executing program logic, and outputting control signals to the executing components.

Data Communication Management

Support data exchange with other control boards or external monitoring systems in the system, achieving coordinated linkage of multi-level control systems.

Signal input/output processing

Supports digital and analog signal input and output, and can be directly connected to various sensors, transmitters, and actuators.

Redundancy and Fault Tolerance Mechanism

Support collaborative operation with other control modules, with fault tolerance and redundancy features, to enhance system reliability.

System diagnostic function

It can perform real-time self inspection and provide feedback on system status information through diagnostic ports or indicator devices, facilitating maintenance and troubleshooting.

technical specifications

Series platform: GE Mark V control system

Interface standard: compatible with VME bus

Working power supply: powered by the system, no need for an external independent power supply

Installation method: Standard rack insertion type

Working temperature range: 0 ° C to 70 ° C

Storage temperature range: -40 ° C to 85 ° C

Module size and weight: Suitable for standard configuration of industrial control cabinets

application area

Gas turbine control system

Steam turbine control system

Power plant automation control platform

industrial process control system

Energy automation systems with high reliability requirements

Product imag
