ALCATEL LUCENT 3DH03164AB transmitter module

ALCATEL LUCENT 3DH03164AB transmitter module

Product Details Introduction

ALCATEL-LUCENT 3DH03164AB transmitter module technical specification

1. Basic specifications

Model: 3DH03164AB

Manufacturer: Alcatel Lucent (Nokia subsidiary)

Equipment type: RF transmitter module

Applicable frequency band: 900MHz (GSM frequency band)

2. Core parameters

Technical specifications

Output power 60W (peak)

Working voltage 28VDC ± 15%

Efficiency>22%

Interface type 7/16 DIN male head

Size 190 × 120 × 45mm (length × width × height)

3. Typical applications

Base station system:

Flexi EDGE BTS base station

Indoor distribution system source

Network Expansion:

Network coverage in rural areas

Subway tunnel signal coverage

4. Installation requirements

Mechanical installation:

Fix with M6 screws

Ensure good ventilation of the radiator

Maximum installation torque: 5Nm

Product imag
