ALCATEL LUCENT 3DH03218ADAA power amplifier module

ALCATEL LUCENT 3DH03218ADAA power amplifier module

Product Details Introduction

ALCATEL-LUCENT 3DH03218ADAA Power Amplifier Module Technical Description

Specification

Model: 3DH03218ADAA

Manufacturer: Alcatel Lucent (now under Nokia)

Type: RF power amplifier module

Working frequency band: 1800MHz (DCS frequency band)

Technical Parameter

Output power: 40W (typical value)

Gain: 50dB (minimum)

Efficiency:> 18%

Supply voltage:+ 28VDC

Interface type: N-type connector

major function

Used for base station transmitter system

Provide RF signal amplification

Support Digital Pre Distortion (DPD) technology

Built in over temperature protection circuit

Application scenarios

2G/4G mobile communication base station

indoor distribution system

Wireless relay device

INSTALLATION REQUIREMENTS

Should be installed in a well ventilated environment

Environmental temperature range: -40 ℃ to+55 ℃

Relative humidity: 5% to 95% (non condensing)

Product imag
