ALCATEL-LUCENT 622-9593-001 I/O Circuit Board

ALCATEL-LUCENT 622-9593-001 I/O Circuit Board

Product Details Introduction

1. Product Overview

Model: 622-9593-001

Type: I/O (Input/Output) Interface Circuit Board

Purpose: Used for signal input/output management of Alcatel Lucent (now Nokia) communication equipment, supporting multiple communication protocols and interface types, suitable for optical transmission, data exchange, and access devices.

2. Core functions and features

(1) Multi protocol interface support

Supported interface types:

Light mouth: SFP/SFP+（1G/10G/25G）

Electrical port: RJ45（10/100/1000BASE-T）

TDM interface: E1/T1 (for traditional voice/dedicated line services)

Synchronization interface: Supports SyncE, 1588v2 (PTP) clock synchronization

(2) High density port configuration

The single board can provide 8 × 10G SFP+or 16 × 1G RJ45 interfaces (specific configuration varies depending on the model variant).

Support port aggregation (LACP) and link redundancy to enhance bandwidth and reliability.

(3) Intelligent traffic management

QoS strategy: Supports traffic priority scheduling based on VLAN and DSCP.

ACL filtering: configurable access control lists to enhance network security.

Statistical Monitoring: Provides port level traffic statistics (RFC 3635).

(4) Hot swappable and redundant design

Support online replacement (OIR, Online Insertion and Removal).

Compatible with 1:1 or N: 1 backup (requires device support).

(5) Low latency&high reliability

Data forwarding delay<10 μ s (64 byte packet).

Compliant with NEBS Level 3 and ETSI telecommunications standards.

3. Typical application scenarios

(1) Optical Transmission Network (OTN/SDH)

Provide customer side service access (such as enterprise dedicated lines) in 1830 PSS equipment.

Support CPRI/OBSAI wireless front-end interface (for 4G/5G base stations).

(2) Data communication equipment

Business interface board for 7750 SR router, providing high-density Ethernet access.

Implement enterprise VPN access in 7450 ESS switch.

(3) Mixed service access

Simultaneously carrying TDM voice, IP data, and video services (such as MSAN devices).

Product imag
