Yaskawa JUSP-ACPCA05JA circuit board

Yaskawa JUSP-ACPCA05JA circuit board

Product Introduction

Yaskawa JUSP-ACPCA05JA circuit board is a power rectifier board for the Yaskawa XRC robot control cabinet, responsible for three-phase AC rectification and providing DC bus power to the servo drive unit.

Product Features

1. Compatible with the Yaskawa Motoman XRC robot system, with high matching of the power supply circuit.

2. The rectified output is stable and can support multiple axis servo loads running simultaneously.

3. Built in fuse and surge absorption circuit to suppress power grid impact.

4. High power component layout with good heat dissipation capability.

5. The plug-in installation of the board makes it convenient for maintenance and replacement inside the robot cabinet.

Application Areas

1. Motoman XRC series robot control cabinet power supply rectification.

2. Multi axis servo power supply unit for welding robots.

3. Conversion of power supply for handling robots.

4. Assemble robot control cabinet matching.

5. Power circuit of spraying robot.

6. Semiconductor mechanical mobile phones are powered by humans.

7. Spare parts for six axis robots in automated production lines.

8. Machine tool loading and unloading robot system.

9. Power rectifier module for palletizing robot.

10. Yaskawa old robot repair kit.

The Yaskawa JUSP-ACPCA05JA circuit board provides a stable DC bus for the entire servo system and is a core power supply spare part for the Yaskawa XRC robot control cabinet.
