Physik E-503K004 High Voltage Amplifier

Physik E-503K004 High Voltage Amplifier

Product Introduction

Physik E-503K004 High Voltage Amplifier

Product Features

Three channel independent piezoelectric drive with stable output voltage gain and excellent linearity

Built in short circuit protection and overheat protection automatically cut off output in case of abnormality

Support DC offset adjustment and fine tune static positioning reference voltage

3U modular board compatible with E500 series chassis for quick insertion and replacement

Low noise amplification output suitable for precise control of nanoscale piezoelectric platforms

Product application areas

Precision focusing displacement mechanism of semiconductor lithography machine

Laser scanning galvanometer piezoelectric driving unit

Optical adaptive mirror adjustment system

Precision Motion Control of Nano Positioning Platform

High speed focusing device for microscope objective lens

MEMS Device Test Driver Platform

Fiber optic alignment coupling precision adjustment equipment

Material micro deformation testing system

Biological microscopy imaging scanning platform

Vacuum chamber piezoelectric actuator driving unit

Product Specifications

Output voltage -30V to 130V

Fixed voltage gain of 10 times

Number of channels: Three channels with independent output

The Physik E-503K004 high-voltage amplifier belongs to the PI piezoelectric power amplification module, which is used to amplify the low-voltage control signal and drive the piezoelectric ceramic actuator to achieve nanometer level high-precision displacement adjustment.
