AMAT 0195-14157 Controller Module

AMAT 0195-14157 Controller Module

Product Introduction

AMAT 0195-14157 Controller Module

Product Features

High precision in multi-channel analog and digital signal acquisition and conversion

Built in signal isolation circuit to resist electromagnetic interference from cavities

Support high-speed backplane communication to achieve real-time process linkage

Modular card structure rack for quick insertion and replacement

Equipped with self checking function for easy on-site troubleshooting

Product application areas

Semiconductor thin film deposition equipment

Plasma etching process chamber

Vacuum chamber signal monitoring system

Wafer temperature closed-loop control system

Gas flow controller signal docking

Vacuum interlock management of semiconductor equipment

Logic control of wafer transfer action

200mm 300mm process platform supporting

Semiconductor RTP heat treatment equipment

Clean workshop process measurement and control unit

Product Specifications

Signal type: 16 bit analog plus digital I/O

Supply voltage 5V DC and 24V DC

Installation method: Rack mounted card

The AMAT 0195-14157 controller module, as the core component of the cavity signal interface, is responsible for data exchange between sensors and actuators inside the semiconductor device cavity to ensure stable operation of the wafer process.

Product imag

ontroller Module
