Product Introduction

The Spellman MX15PN24/741 power module is an OEM high voltage power module specifically designed for Precision Instruments, providing high-precision high voltage output for mass spectrometry and optical analysis equipment.

Product Features:

1. High voltage output is stable, with low ripple noise, ensuring consistency of ion detection signals.

2. Built in rapid protection against arcing, overcurrent, and overvoltage to prevent damage to the high-voltage circuit.

3. Compact packaging for easy integration into precision analytical instruments.

4. Supports analog control and can adjust high-voltage output parameters in real time.

5. Anti temperature drift design, with minimal voltage drift during long-term operation.

Application fields:

6. High voltage power supply unit for ion source of mass spectrometer.

7. High voltage drive module for electron multiplier.

8. Ionic optical analysis instrument.

9. Vacuum detection precision equipment.

10. Gas chromatography-mass spectrometry instrument.

11. Material surface analysis equipment.

12. Precision analytical instruments in research laboratories.

13. Ionic optical lens power supply system.

14. Replacement of spare parts for Spellman analytical instruments.

15. High voltage unit for precision electronic testing equipment.

Product Parameters:

16. Module type: Embedded precision high-voltage DC power supply.

17. Power input: DC24V.

18. Equipped with high-voltage monitoring feedback and fault signal output.

The Spellman MX15PN24/741 power module is a core high-voltage power supply spare part for precision analytical instruments, which stably maintains the high-voltage working conditions of ion sources and optical components.

Product imag
